Townsend Security Data Privacy Blog

Microsoft SQL Server Encryption Key Management

Posted by Patrick Townsend on Mar 20, 2017 2:01:48 PM

The hardest part of an encryption strategy is the proper management of encryption keys. Failing to protect encryption keys puts protected data at risk, and fails to meet security best practices and compliance regulations. For Microsoft SQL Server customers who have already implemented Transparent Data Encryption (TDE) or Cell Level Encryption (CLE) the biggest cause of an audit failure is the lack of good encryption key management.

Encryption-Key-Management-SQL-Server This is the fourth in a series on the topic of Microsoft SQL Server encryption. Let’s look at some of the characteristics of good encryption key management for SQL Server.

Extensible Key Management (EKM) Providers
As we’ve discussed previously it is the responsibility of key management vendors to provide the Extensible Key Management (EKM) Provider software that is installed and registered to the SQL Server database enabling either TDE or CLE encryption. The software from the key management vendor is installed on the SQL Server instance and provides both encryption and key management services. The SQL Server database administrator does not need to be involved in the actual retrieval of an encryption key - that is the job of the EKM Provider software.

EKM Provider software must handle the encryption and decryption of the database key for Transparent Data Encryption, and must handle the retrieval of a symmetric key for Cell Level Encryption. Key retrieval should be performed in a manner that protects the encryption key from loss on the network, protects the key while in memory, and should properly log the key retrieval event in a system log repository. Encryption key retrieval is normally protected through the use of a secure TLS network connection between the EKM Provider software on SQL Server and the key manager hardware or virtual machine. There are many other critical aspects of EKM Provider key management implementations, and these will be discussed in a future series.

Enterprise Key Management Solutions
The proper generation, storage, protection and management of encryption keys is the core purpose of professional encryption key management solutions. As security devices an encryption key manager is responsible for creating strong encryption keys that meet industry standards, and protecting those keys from loss during the lifecycle of the keys. Encryption key managers may be hardware security modules (HSMs), virtual servers (VMware, Hyper-V, etc.), or multi-tenant or dedicated cloud instances. In addition to implementing industry standards for encryption key management, key servers will provide a variety of authentication, systems management, and audit functions to meet security best practices and compliance regulations. Microsoft SQL Server customers who want to achieve compliance with common regulations should look to deploy a professional, certified and validated key management solution.

Key Management Industry Standards
Encryption key management systems are cryptographic modules that perform a variety of functions. As a cryptographic module they fall under the standards of the National Institute of Standards and Technology (NIST) and key managers should provably meet NIST standards. The relevant NIST standard for encryption key management is the Federal Information Processing Standard 140-2 (FIPS 140-2), “Security Requirements for Cryptographic Modules”. Key management solutions which implement FIPS 140-2 standards will insure the generation of strong encryption keys, the protection of those keys from corruption or substitution, and the implementation of encryption that provably meets NIST cryptographic standards.

In addition to provide standards for encryption key management NIST also provides a method for vendors to validate that their solutions meet the standard. Encryption key management solutions are tested by chartered security testing laboratories and solutions are then approved directly by NIST. NIST publishes the solutions that have passed FIPS 140-2 testing and Microsoft SQL Server customers should look for FIPS 140-2 validation of any key management solution used to protect the database.

Migrating Locally Stored Keys to Key Management
Many Microsoft SQL Server users start their encryption projects by using the option to locally store the database encryption key on the local SQL Server instance. While this is not a security best practice, it is a common way to start an encryption project.

Fortunately, it is easy to migrate a locally stored encryption key to a proper key management solution. The migration involves the protection of the SQL Server database key to key management protection and does not require the decryption of the database. The database key which is currently protected by local keys and certificates is placed under the protection of the key manager. The EKM Provider software of your vendor then becomes responsible for unlocking the database key (TDE) or retrieving the symmetric key for Cell Level Encryption (CLE).

OASIS Key Management Interoperability Protocol (KMIP)
Many SQL Server customers ask about the KMIP standard for integrating with key managers. While KMIP is important for many reasons, it does not apply to the Microsoft EKM Provider interface. The EKM Provider interface leaves it to the key management vendor to perform the needed cryptographic functions on the key server. These functions do not map to KMIP operations and attributes. While it is advisable to deploy key management solutions that meet KMIP standards, it is not required for SQL Server encryption.

To this point we have defined the SQL Server encryption architecture, options for implementing SQL Server encryption (TDE and CLE), and basic requirements for encryption key management. In the next part of this series we will look at EKM Provider implementation topics as well as business continuity topics.

Patrick
Encryption and Key Management for Microsoft SQL Server

Topics: SQL Server, SQL Server encryption

Microsoft SQL Server Automatic Encryption - Cell Level Encryption

Posted by Patrick Townsend on Feb 21, 2017 9:11:00 AM

In this third part of the series on Microsoft SQL Server encryption we look at Cell Level Encryption, or CLE, which is Microsoft terminology for Column Level Encryption. With CLE the manner and timing of SQL Server’s call to the EKM Provider software is quite different than for Transparent Data Encryption. It is important to understand these differences in order to know when to use CLE or TDE. Let’s look at some aspects of the CLE implementation:

Encrypted Columns
Encryption-Key-Management-SQL-Server Cell Level Encryption is implemented at the column level in a SQL Server table. Only the column you specify for encryption is protected with strong encryption. You can specify more than one column for CLE in your tables, but care should be taken to avoid performance impacts of multiple column encryption (see below).

With Cell Level Encryption you may be able to minimize some of the encryption performance impacts on your SQL Server database. Because the EKM Provider is only called when the column must be encrypted or decrypted, you can reduce the encryption overhead with careful implementation of your database application code. If a SQL query does not reference an encrypted column, the EKM Provider will not be invoked to perform decryption. As an example, if you place the column Credit_Card under CLE encryption control, this query will not invoke the EKM Provider for decryption because the credit card number is not returned in the query result:

SELECT Customer_Number, Customer_Name, Customer_Address FROM Orders ORDERBY Customer_Name;

You can see that judicious use of SQL queries may reduce the need to encrypt and decrypt column data.

SQL Application Changes
Unlike Transparent Data Encryption you must make a change to the SQL statement in order to implement Cell Level Encryption. The SQL Server functions “encryptbykey” and “decryptbykey” are used on SQL statements. Here is an example of a SQL query that encrypts a CLE-encrypted column:

select encryptbykey(key_guid('my_key'), 'Hello World');

Implementing CLE encryption in your SQL Server database requires modifications to your applications, but may be well worth the additional work.

Encryption and Key Retrieval
The EKM Provider software is called for each column value to perform encryption and decryption. This means a larger number of calls to the EKM Provider compared to Transparent Data Encryption. Because the number of calls to the EKM Provider may be quite large it is important that the encryption and key management functions of the EKM Provider are highly optimized for performance (see the next section).

The EKM Provider software from your key management vendor is responsible for performing encryption of the data. From a compliance point of view it is important to understand the encryption algorithm used to protect data. Be sure that the EKM Provider software uses a standard like the Advanced Encryption Standard (AES) or other industry recognized standard for encryption. It is common to use 128-bit or 256-bit AES for protecting data at rest. Avoid EKM Providers which implement non-standard encryption algorithms.

Encryption Key Caching
When deploying CLE it is important that the EKM Provider software optimize both encryption and key management. The number of calls to the EKM Provider software can be quite high. Good EKM Providers will securely cache the symmetric key in the SQL Server context rather than retrieve a key on each call. The retrieval of an encryption key from a key server takes precious time and multiple calls to retrieve a key can have severe performance impacts. Secure key caching is important for CLE performance. The use of the Microsoft Windows Data Protection Application Program Interface (DPAPI) is commonly used to protect cached keys.

Performance Considerations
When properly implemented Cell Level Encryption can reduce the performance impact of encryption on your SQL Server database. For very large tables with a small number of columns under encryption control, the performance savings can be substantial. This is especially true if the column is used less frequently in your applications.

CLE Vendor Note
Note that each vendor of EKM Provider software implements encryption and key management differently. Some EKM Providers only implement Transparent Data Encryption (TDE). If you suspect you will need Cell Level Encryption be sure that your key management support includes this capability.

In the next part of this series we will look at encryption key management in SQL Server.

Patrick

Encryption and Key Management for Microsoft SQL Server

Topics: SQL Server, Cell Level Encryption, SQL Server encryption

4 Ways to Encrypt Data in Microsoft SQL Server

Posted by Patrick Townsend on May 6, 2013 4:29:00 PM

Almost every organization has at least one application built on Microsoft’s SQL Server database. Whether you build an application in-house using Microsoft’s development tools or you deploy a software package from a software vendor, chances are that your organizations has one or more SQL Server databases to help you manage information.

The Challenge: Protect Data with SQL Server’s Encryption

Encryption-Key-Management-SQL-Server Today it is almost impossible to run a business without handling sensitive information and storing storing data such as customer names, credit card numbers, bank account numbers, passwords, email addresses, or other personally identifiable information (PII) or private health information (PHI) in your SQL Server database. If your organization must meet data security regulations such as PCI-DSS, HIPAA/HITECH, or GLBA/FFIEC, you probably already know that this data must be encrypted in order to protect your customers and prevent data loss in the event of a data breach.

What you may not know is that in order to truly protect your data, you must manage your encryption keys in adherence to key management best practices such as dual control and separation of duties using an external encryption key manager (key managers are available in VMware, Cloud, as a traditional harware security moule or HSM). Your company will only be able to avoid data breach notification if you are using these best practices.

The good news is that SQL Server 2008-2016 comes equipped with transparent data encryption (TDE) and extensible key management (EKM) to make encryption and key management using a third-party key manager easier than ever. Older versions of SQL Server can also be easily encrypted using different tactics, and you can manage those encryption keys just as easily with an encryption key manager as well.

Encrypting Data in SQL Server Depends on Your Version

If you’re currently looking into encrypting your SQL Server database or deploying a key management system, you may be concerned about how to protect your data depending on the version, code, and language used to build your database. To help ease your worries, here are 4 ways to encrypt your SQL Server database and protect your encryption keys:

  1. Since SQL Server 2008 Microsoft has supported automatic encryption with TDE and cell level encryption for Enterprise Edition users and above. Without any programming you can encrypt the SQL Server database or an individual column, and store the keys on an encryption key management HSM.
  2. If you have an older version of SQL Server, or you have SQL Server Standard Edition or Web Edition, you don’t have access to TDE. But you can still automate encryption: Through the strategic use of SQL Views and Triggers, you can automate encryption of sensitive data on your SQL Server without extensive program modifications, and still use a secure key managemer to protect the encryption keys.
  3. Your developers might have written custom application code to implement your SQL Server database. But SQL Server encryption and key management is still within your reach. A good key management vendor should supply you with software libraries that easily add into your applications and implement SQL Server encryption.
  4. You might have a SQL Server database, but not be using Microsoft programming languages. Perhaps your applications are written in Java, Perl, or PHP. Again, it is simple to deploy software libraries that encrypt the SQL Server data and which store the encryption keys on an external centralized key manager.

SQL Server encryption and good key management is not difficult to achieve. Although key management has a reputation for being difficult and costly, today key management for SQL Server is cost-effective, easy, has little to no performance impact, will get your company in compliance, and will keep your organization out of the headlines by helping to prevent a data breach.

To learn more about key management for SQL Server, download the White Paper, “Encryption Key Management for Microsoft SQL Server 2008/2016.”

Encryption and Key Management for Microsoft SQL Server



Topics: Extensible Key Management (EKM), Microsoft, Encryption Key Management, White Paper, SQL Server, SQL Server encryption
