Townsend Security Data Privacy Blog

IBM SoftLayer, VMware and Getting to the Secure Cloud

Posted by Patrick Townsend on Aug 1, 2016 8:27:33 AM

VMware customers have experienced some frustration around cloud migrations for quite some time. While VMware has attempted to provide a path to the cloud through their vCloud strategy, substantial barriers have made the migration difficult to achieve. While VMware customers have achieved substantial cost and efficiency savings through VMware technologies, they have largely not been able to extend these benefit through cloud migrations. The new IBM and VMware partnership is changing this.

Encrypting Data in IBM SoftLayerThere are two aspects of the partnership that make this very different than other cloud offerings for VMware:

  • IBM will create dedicated cloud resources for VMware customers who migrate, essentially creating a private cloud platform. This will alleviate many of the concerns of Enterprise customers about the security of their cloud migration.
  • IBM has negotiated great pricing for VMware applications on the IBM SoftLayer cloud. This will let VMware customers experience an immediate ROI on the cloud migration.

VMware customers have invested a great deal in the architecture and administration of their VMware environments. VMware applications let customers create secure segmented networks, apply security and access controls, monitor the status of their applications, automate business recovery operations, and perform an number of other administrative functions in a coherent and cost-effective manner. Finding a way to the cloud that leverages benefits is crucial for the VMware customer.

I think IBM has found the right path for these customers.

IBM is not the first to attempt to address the needs of the VMware customer. Rackspace and others have cloud migration plans and have been working with VMware customers. But I think IBM SoftLayer has solved some problems that will open the path to VMware in the cloud.

One of the remaining challenges for VMware customers is to get their third-party application and security vendors to embrace this move to the cloud. While the IBM VMware offering is a true native VMware implementation that will reduce the technical issues, software vendors need to be explicit about their support for solutions deployed on a cloud platform. VMware customers can find it confusing and frustrating to get clear statements of support from vendors.

At Townsend Security we are trying to support our customers migrating our products in VMware to the IBM SoftLayer cloud. Our Alliance Key Manager and related encryption products are already validated for deployment in VMware. And we’ve extended our support for the VMware platform by validating our encryption and key management to the PCI Data Security Standard. We now also support the migration or deployment of our solutions in the IBM SoftLayer cloud. This gives IBM SoftLayer customers the confidence of moving their encryption security infrastructure to the IBM SoftLayer platform.

It has been amazing how the PCI-DSS validation of our solutions in VMware have helped VMware customers meet PCI requirements. VMware deserves a lot of credit for creating a formal program for PCI validation on a well-defined VMware reference architecture. Working with Coalfire, a security auditing firm, we were able to very quickly certify our encryption and key management solutions to the PCI-DSS standard. This has helped multiple customers quickly move through the compliance challenge and this applies to the IBM SoftLayer platform, too. Because IBM SoftLayer retains the dedicated resources for the customer, compliance will be easy to achieve.

IBM and VMware have created a great path to the cloud for VMware customers. I know that many challenges will remain for customers with more complex VMware architectures, especially with hybrid environments. But I think the path to the cloud just got a bit straighter and easier.

Patrick

Encrypting

Topics: VMware, Cloud Security

PCI DSS Requirements 3

Posted by Luke Probasco on Jul 22, 2015 12:52:00 PM

NIck Trenc - CoalfireThis is a guest blog by Nick Trenc, CISSP, QSA, PA-QSA, VCP.  Nick is an IT Security Architect at Coalfire Labs.


For those protecting the front lines of our credit card data in merchant environments, few other things keep those in charge (as well as IT administrators) awake at night than the threat of a breach. Questions often arise along the lines of: Will my company be able to survive? What can I do to protect myself? How do I prevent my company from being next? And how do I limit any losses should it happen to us?

VMware Encryption Key Management PCIOne of the key components to the protection of cardholder data at any merchant location is the use of strong cryptography along with just-as-strong cryptographic key management procedures. PCI DSS Requirement 3 outlines what the PCI council believes to be the baseline for strong cryptographic key management procedures and is a key element of any PCI DSS audit.

Successful key management with a strong cryptographic algorithm is the best place to start with getting encryption of your cardholder data correctly protected while it is contained within your environment. But key management can be confusing, difficult and downright impossible depending on the size of your environment. Figuring out if your keys are strong enough, or if they are rotated often enough or if they are protected from would-be hackers. On top of that, figure in the ever-increasing complexity of today’s business systems to include cloud, virtual computing, data mining, and others, the ability to quickly and easy manage encryption keys across several platforms and environments becomes key for PCI DSS compliance.

This is where a tool like Townsend Security's Alliance Key Manager (AKM) comes in to play. Available as a physical hardware security module (HSM), a cloud HSM, a virtual appliance (VMware) or in the cloud (AWS, Azure), Alliance Key Manager can help merchants meet PCI DSS requirements for encryption key management by creating, managing, and distributing AES 128-bit, 192-bit or 256-bit encryption keys all without the risks involved with clear-text key administration.

As a QSA, it is certainly encouraging to see a complete encryption solution that removes some of the worries of traditional manual clear-text key management procedures. AKM can relieve pressure to meet portions of PCI DSS Requirement 3 such as the need to render Personal Account Numbers (PAN) unreadable using strong cryptography with associated key-management processes and procedures (PCI DSS 3.4). It directly meets PCI DSS Requirement 3.5.2 to store keys within a secure cryptographic devices such as a HSM along with additional encryption requirements such as 3.6.2 – Secure Key Distribution, and 3.6.3 – Secure Key Storage. In addition, AKM can make PCI DSS Requirements 3.6.6 for Split Knowledge and Dual Control not applicable as there are no manual key-management operations involved. This (virtual) device is a useful cost-effective tool to help meet your PCI DSS compliance.

For more information on using AKM to meet PCI DSS compliance specifically within a virtual environment (but also applicable to most environments), please see the VMware Product Applicability Guide for PCI DSS 3.0 published by Coalfire Systems with collaboration with Townsend Security and VMware.

VMware Encryption Key Management PCI DSS

Topics: Alliance Key Manager, VMware

Overcome Security Challenges with Your VMware Environment

Posted by Michelle Larson on Apr 15, 2015 10:29:00 AM

Prioritize Your Data Security Plan and Encryption Strategy

New Call-to-actionMany businesses migrating to VMware environments are storing or processing credit card numbers, financial information, health care data, and other personally identifiable information (PII) in a virtual, shared environment. How does an organization meet industry data security requirements and prevent unwanted access to sensitive data?

In order to achieve a comprehensive data security plan in a VMware environment, organizations should consider the following steps:

Take Inventory of Your Sensitive Data

Every data security project should start by making an inventory of sensitive data in your IT environment. If you do not know where to start, first consider the compliance regulations you fall under. For example, do you process credit cards? If so, you must locate and encrypt primary account numbers (PAN), expiration date, cardholder name, and service codes where they are processed, transmitted, or stored in order to meet PCI compliance. If your company is a financial institution, include Non-Public Information (NPI) about consumers, and if you are in the medical segment, you must also locate all Protected Health Information (PHI) for patients. Finally, locate all data that is considered Personally Identifiable Information (PII) which is any information that can uniquely identify an individual (social security number, phone number, email address, etc.). Business plans, computer source code, and other digital assets should make the list, too.

Once you have a list of the kinds of information that you should protect, find and document the places this information is stored. This will include databases in your virtual machines, unstructured data in content management systems, log files, and everywhere else sensitive data comes to rest or can be found in the clear.

After you have a full inventory of your sensitive data, prioritize your plan of attack to secure that information with encryption and protect your encryption keys with a key management solution. The most sensitive information, such as credit card numbers, medical or financial data, is more valuable to cyber criminals and should be encrypted first. Creating this map of where your sensitive data resides and prioritizing which data to encrypt is not only a requirement for many compliance regulations, but will help to focus your resources as well.

What to do:

  • Define sensitive data for your organization.
  • Using manual and automated procedures, make an inventory of all of the places you process and store sensitive data.
  • Create a prioritized plan on how you will encrypt the sensitive information affected by compliance regulations.

Implement Encryption and Encryption Key Management

While encryption is critical to protecting data, it is only half of the equation. Your key management solution will determine how effective your data security strategy ultimately is. When encrypting information in your applications and databases, it is crucial to protect encryption keys from loss. Storing encryption keys with the data they protect, or using non-standard methods of key storage, will not protect you in the event of a data breach.

For businesses who are already encrypting data, the most common cause of an audit failure is improper storage and protection of the encryption keys. Doing encryption key management right is often the hardest part of securing data. For this reason, it is paramount to choose a key management solution that is compliant and tested against the highest standards:

  • Your VMware key management solution should be based on FIPS 140-2 compliant key management software (find out if your key management vendor offers FIPS 140-2 compliant key management on the NIST website look it up on the NIST web site.
  • A key management solution should also conform to the industry standard Key Management Interoperability Protocol (KMIP) as published by OASIS. Ask for the KMIP Interoperability Report from the KMIP testing process.

Encrypting sensitive data on your virtual machine protects your data at the source, and is the only way to definitively prevent unwanted access to sensitive data. With VMware environments, businesses that need to protect sensitive data can use encryption and encryption key management to secure data, comply with industry security standards, protect against data loss, and help prevent data breaches.

What to look for:

  • Use industry standard encryption algorithms such as AES to protect your sensitive data. Avoid non-standard encryption methods.
  • Your encryption solution should support installation in any application workgroup that you define for your trusted applications. Be sure your encryption vendor explains any limitations in the VMware deployment.
  • Your encryption key management solution should support deployment in a separate VMware security workgroup. Ideally, the key management solution will include internal firewall support to complement the VMware virtual firewall implementation.
  • Your key management solution is a critical part of your VMware security implementation. It should support active collection and monitoring of audit logs and operating system logs. These logs should integrate with your log collection and SIEM active monitoring systems.

As your IT environment evolves, make sure your key management evolves with you. In addition to support for VMware, be sure your key management solution is available as a hardware security module (HSM), as a Cloud HSM subscription, and as a native cloud application on major cloud service provider platforms such as Amazon Web Services and Microsoft Azure. Even if you do not have these non-VMware platforms today, it is important to consider that the evolution of your IT infrastructure is inevitable. The encryption and key management solutions you deploy today in your VMware data center should be prepared to move to cloud or hosted platforms quickly and seamlessly. A merger, acquisition, rapid growth, competitive challenges, and technology advances can force the need to migrate your solutions to new platforms.

For more detailed information, check out our eBook on VMware Encryption – 9 Critical Components of a Defensible Encryption Strategy:

VMware Encryption eBook

Topics: Alliance Key Manager, Data Security, eBook, Encryption Key Management, VMware

Understanding Encryption and Key Management for VMware

Posted by Michelle Larson on Apr 3, 2015 11:33:00 AM

How to implement solutions that are based on compliance standards and meet security best practices.

As more and more Enterprise businesses move into virtual and cloud environments, they face challenges and security issues in these multi-tenancy situations. VMware customers benefit from the many operational and cost efficiencies provided by VMware virtualization technologies both in traditional IT infrastructure and in cloud environments. VMware Resource Kit for Encryption and Key ManagementAs VMware customers deploy data encryption solutions as a part of their defense-in-depth strategy, the need for compliant encryption key management can present barriers to a good encryption implementation. It is possible to deploy a proper encryption key management solution within the VMware infrastructure without the need for traditional hardware security modules (HSMs) when this approach is appropriate to the security needs of the organization.

Here is some high level guidance on how to deploy and protect a solid encryption and key management solution for VMware within your virtual or cloud environment. While these recommendations are general in nature (actual VMware deployments will use different VMware applications and architectures to meet specific user, application, and security needs) they can provide a good roadmap.

Seven General VMware Recommendations

1. Identify and Document Trusted and Un-Trusted Applications

Properly identifying application groups based on the level of trust is critical for a secure implementation of virtualized applications and encryption key management services. Create and isolate a management cluster for your core VMware applications such as vSphere, vShield, etc. Identify application groups and their associated level of trust, and isolate applications into appropriate workgroups. Avoid mixing trusted and untrusted applications in a workgroup.

You should consider creating a security workgroup to contain your third party security applications such as encryption key management, authentication services, active directory, system logging, and other applications whose primary function is to assist in securing your applications in your VMware environment.

In preparation for properly securing these environments, create an inventory of all Virtual Machines managed in each workgroup. For each workgroup and virtual machine, identify the security controls that will be required for each one (network segmentation, storage segmentation, system logging, active monitoring, etc.). VMware flow tools can assist with this documentation.

2. Restrict Physical Access

Fundamental to all IT security implementations is proper security of the physical environment. This means proper physical security controls and physical monitoring of the data center as well as good auditing and procedural controls. These physical controls should also apply to access of VMware management and security applications. You can look to the PCI Data Security Standards and guidance for information on appropriate physical controls. You can also refer to standard security guidance in SOC 2 and SOC 3 assessments for information on physical controls. When deploying on a cloud platform it is always a good idea to ask the Cloud Security Provider (CSP) for a copy of the PCI letter of attestation, or an SOC 2 / SOC 3 report.

3. Isolate Security Functions

Because security applications are often a target of cyber-criminals, you should isolate them into their own security workgroup and implement the highest level of VMware security. Only trusted VMware administrators should have access rights to the encryption key management solution, system logs, and audit reports. Be sure to actively monitor access to and use of all encryption key management, key retrieval, and encryption services.

4. Change VMware Default Passwords

Review all VMware applications used to secure and manage your VMware environment and change the default passwords as recommended by VMware. The failure to change default passwords is one of the most common causes of security breaches.

5. Implement Network Segmentation

Network segmentation is easy to accomplish with VMware network management and security applications and you should implement network segmentation to isolate applications that process sensitive information from applications that do not require as high a level of trust. Additionally, you should provide network segmentation for all third party security applications such as your encryption and key management solution. Network segmentation should include all high availability and business recovery infrastructure. Do not rely on virtual network segmentation alone; use firewalls that are capable of properly securing virtual networks.

6. Implement Defense in Depth

The VMware management and security applications provide for a high level of security and monitoring. They also provide hooks and integration with third party security applications that provide system log collection, active monitoring, intrusion detection, etc. Encryption is a critical part of a defense-in-depth strategy, and protecting encryption keys is the most important part of an encryption strategy. Regardless of the operating systems in your application Virtual Machines, your solution should provide encryption key management, key retrieval, and encryption services for your business applications and databases running in your VMware infrastructure.

7. Monitor VMware Administrative Activity

Use an appropriate SIEM solution to collect VMware application and ESXi hypervisor system logs and perform active monitoring. The log collection and SIEM active monitoring solutions should be isolated into a security workgroup that contains other third party security applications such as Townsend Security’s Alliance Key Manager.

For additional information on securing Alliance Key Manager for VMware, our encryption key management solution, request the VMware Resource Kit containing the Guidance Document and other valuable resources:

Resource Kit: Encryption and Key Management in VMware

As solutions and implementations vary a great deal, always consult with a security specialist and compliance auditor for specific guidelines for your industry and environment! Just contact us to get started!

Topics: Compliance, Data Security, Encryption Key Management, Defense-in-Depth, VMware, Resource Kit

VMware Encryption - 9 Components of a Defensible Encryption Strategy

Posted by Liz Townsend on Feb 11, 2015 2:37:00 PM

VMware Encryption eBookWe all know encrypting sensitive data such as customer, employee, and business critical data is not only crucial to protecting your company’s assets, encryption is also required by industry regulations such as the Payment Card Industry Security Standards Council (PCI SSC) and GLBA/FFIEC. Today businesses are turning to VMware virtual machines and the cloud to reduce cost and complexity within their IT environments. When companies set out to encrypt sensitive data that is stored or processed in VMware, meeting industry regulations is top of mind. Businesses also sometimes assume that meeting the encryption requirements of a regulation will protect them from a data breach as well. Unfortunately, passing a data security audit does not always guarantee a strong defense to a data breach. Where data is encrypted and how it is encrypted is often subjective to the auditor, and where one auditor might give your encryption solution a passing grade, another might fail you. If you are only looking for a passing grade, you may be implementing the bare minimum requirements. When you consider the possible deviation between one auditor to the next, it becomes clear that meeting compliance is often a low bar.

At Townsend Security we help our customers not only meet compliance, but achieve a level of security in their VMware environment that will protect them in the event of a data breach. Our new eBook, “VMware Encryption: 9 Critical Components of a Defensible Encryption Strategy,” discusses nine strategies for ensuring your VMware encryption strategy is strong enough to protect your business in the event of a data breach.

Download this eBook to learn more about these critical components and more:

1. Establish a VMware Security Roadmap
The first step in securing your VMware environment is to establish a security roadmap. Determine how encryption and key management in VMware fit into a holistic security plan, and assess security requirements that compliance regulations mandate. Assess your level of risk tolerance for the types of data you want to protect. It’s important to keep in mind that compliance regulations may not mandate the protection of some data, such as email addresses and passwords; however, you may want to encrypt this data in order to protect your brand and reputation should this data get breached. At an IT level, like other security applications that perform intrusion detection/prevention, and active monitoring, you should deploy your encryption key management virtual machine in a separate security workgroup and provide administrative controls in the same way as for other VMware and third party security applications. [Download the eBook to read more]

2. Inventory and Prioritize Sensitive Data
Every encryption project should start by making an inventory of sensitive data in your IT environment. The first step is to define “sensitive data.” Sensitive data is any customer or internal data that you must protect in order to meet compliance requirements or protect your customers, employees, and yourself from data theft and fraud. The scope of what is considered “sensitive data” and how hackers use data to commit fraud is growing. However, if you do not know where to start, first consider the compliance regulations you fall under. [Download the eBook to read more]

3. Use Industry Standard AES Encryption
Encryption protects your data at the source and is the only way to definitively prevent unwanted access to sensitive data. Academic and professional cryptographers have given us a number of encryption algorithms that you can use to protect sensitive data. Some have interesting names like Twofish, Blowfish, Serpent, Homomorphic, and GOST; however, it is critical in any professional business to use encryption algorithms accepted as international standards. Many compliance regulations require the use of standard encryption, such as AES, a globally recognized encryption standard, for encrypting data at rest. [Download the eBook to read more]

4. Encryption Key Management

Many organizations that encrypt sensitive data fail to implement an adequate encryption key management solution. While encryption is critical to protecting data, it is only half of the solution. Your key management will determine how effective your encryption strategy ultimately is. When encrypting information in your applications and databases, it is crucial to protect encryption keys from loss. Storing encryption keys with the data they protect, or using non-standard methods of key storage, will not protect you in the event of a data breach. For businesses that are already encrypting data, the most common cause of an audit failure is improper storage and protection of the encryption keys. [Download the eBook to read more]

Download “VMware Encryption: 9 Critical Components of a Defensible Encryption Strategy,” to learn 5 more critical components! Learn how to protect your customers, secure your business assets, avoid regulatory fines, and protect your brand.

VMware Encryption eBook

Topics: Encryption, Encryption Key Management, VMware

Securing Alliance Key Manager for VMware

Posted by Michelle Larson on Dec 23, 2014 11:00:00 AM

An Introduction to Townsend Security's VMware Guidance Document

VMware customers benefit from the many operational, and cost efficiencies provided by VMware virtualization technologies both in traditional IT infrastructure and in cloud environments. As VMware customers deploy data encryption solutions as a part of their defense-in-depth strategy, the need for encryption key management can present barriers to a good encryption implementation. This article provides high-level guidance, general in nature, on how deploy and protect Alliance Key Manager for VMware within your VMware environment. Actual VMware deployments of Alliance Key Manager for VMware will use different VMware applications and architectures to meet specific user, application, and security needs.

General VMware RecommendationsVMware Resource Kit for Encryption and Key Management

Identify and Document Trusted and Un-Trusted Applications

Properly identifying application groups based on the level of trust is critical for a secure implementation of virtualized applications and encryption key management services. Create and isolate a management cluster for your core VMware applications such as vSphere, vShield, etc. Identify application groups and their associated level of trust, and isolate applications into appropriate application workgroups. Avoid mixing trusted and untrusted applications in a workgroup.

You should consider creating a security workgroup to contain your third party security applications such as encryption key management, authentication services, active directory, system logging, and other applications whose primary function is to assist in securing your VMware environment. Encryption key management services provide by Alliance Key Manager should be implemented in this separate security workgroup used for critical, non-VMware security applications.

In preparation for properly securing these environments, create an inventory of all Virtual Machines managed in each workgroup. For each workgroup and virtual machine, identify the security controls that will be required for each one (network segmentation, storage segmentation, system logging, active monitoring, etc.). VMware flow tools can assist with this documentation.

Restrict Physical Access

Fundamental to all IT security implementations is proper security of the physical environment. This means proper physical security controls and physical monitoring of the data center as well as good auditing and procedural controls. These physical controls should also apply to access to VMware management and security applications. You can look to the PCI Data Security Standards and guidance for information on appropriate physical controls. You can also refer to standard security guidance in SOC 2 and SOC 3 assessments for information on physical controls. When deploying on a cloud platform it is always a good idea to ask the Cloud Security Provider (CSP) for a copy of the PCI letter of attestation, or an SOC 2 / SOC 3 report.

Isolate Security Functions

Because security applications are often a target of cybercriminals, you should isolate them into their own security workgroup and implement the highest level of VMware security. Only trusted VMware administrators should have access rights to Alliance Key Manager, system logs, and audit reports. Be sure to actively monitor access to and use of all encryption key management, key retrieval, and encryption services.

Change VMware Default Passwords

Review all VMware applications used to secure and manage your VMware environment and change the default passwords as recommended by VMware. The failure to change default passwords is one of the most common causes of security breaches.

Implement Network Segmentation

Network segmentation is easy to accomplish with VMware network management and security applications and you should implement network segmentation to isolate applications that process sensitive information from applications that do not require as high a level of trust. Additionally, you should provide network segmentation for all third party security applications such as Alliance Key Manager. Network segmentation should include all high availability and business recovery infrastructure. Do not rely on virtual network segmentation alone; use firewalls that are capable of properly securing virtual networks.

Implement Defense in Depth

The VMware management and security applications provide for a high level of security and monitoring. They also provide hooks and integration with third party security applications that provide system log collection, active monitoring, intrusion detection,etc. Encryption is a critical part of a defense-in-depth strategy, and protecting encryption keys is the most important part of an encryption strategy. Regardless of the operating systems in your application Virtual Machines, Alliance Key Manager will provide encryption key management, key retrieval, and encryption services for your business applications and databases running in your VMware infrastructure.

Monitor VMware Administrative Activity

Use an appropriate SIEM solution to collect VMware application and ESXi hypervisor system logs and perform active monitoring. The log collection and SIEM active monitoring solutions should be isolated into a security workgroup that contains other third party security applications such as Alliance Key Manager.

For more detailed information, read the entire VMware Guidance Document and other materials available in this VMware Resource Kit:

Resource Kit: Encryption and Key Management in VMware

Topics: Data Security, Encryption, Best Practices, Encryption Key Management, VMware, Resource Kit, Cloud Security

VMware and SQL Server Encryption

Posted by Michelle Larson on Dec 12, 2014 9:38:00 AM

Questions and Answers on Encryption and Key Management Projects

VMware® is hands-down the virtualization choice of large and small organizations, and it is easy to see why. Not only is it a highly reliable and scalable platform, VMware also provides a complete set of tools you need to deploy, manage, monitor, and protect virtual machines.

Earlier this month, Paul Taylor with Security Insider - Podcast Edition spoke with our founder, Patrick Townsend about encrypting data on Microsoft SQL Server in VMware environments, steps to encrypting data on SQL Server (with and without TDE), as well as talk about Townsend Security’s Alliance Key Manager for VMware. Here are a few highlights (download the podcast for the whole conversation):Podcast: VMware and SQL Server Encryption

Paul Taylor: We’ve talked about the Townsend Security encryption and key management solutions for VMware. Today let’s put the focus on Microsoft SQL Server and encryption in the VMware customer environment. Can you give us an overview of how VMware customers can protect data in SQL Server databases?

Patrick Townsend: Just to recap, we really need two things to get encryption right: A key management solution to protect the critical encryption keys, and an encryption solution for the SQL Server database. And they have to talk to each other.

For the first part, our Alliance Key Manager for VMware solution provides a fully functional, enterprise key management solution that protects SQL Server databases as well as other databases and other operating systems.

For encrypting SQL Server, our Alliance Key Manager solution comes with a full Microsoft SQL Server Extensible Key Management Provider. We call this Key Connection for SQL Server and it is one of the modules that our key management customers receive without paying additional license fees. Key Connection for SQL Server provides the encryption and integration with our key server to provide a complete, end-to-end solution for encrypting data in the SQL Server database.

Paul Taylor: Can you talk a little about how Microsoft enables encryption in SQL Server?

Patrick Townsend: If you are running SQL Server Enterprise Edition or higher, you have access to Microsoft’s automatic, full database encryption facility called Transparent Data Encryption, or TDE. You also have access to Microsoft’s automatic, column level encryption facility which Microsoft calls Cell Level Encryption. Both of these options, TDE and Cell Level Encryption,  are implemented without any programming work at all. And both are fully supported by Alliance Key Manager and the Key Connection for SQL Server software from Townsend Security.

Paul Taylor: What about Microsoft customers who aren’t using the Enterprise Edition of SQL Server? Can they encrypt their data with the Townsend Security solution?

Patrick Townsend:  With SQL Server Standard and Web Editions we provide two paths to encrypt data. The first is to use SQL Views and Triggers along with our .NET DLL to provide automatic encryption without any changes to applications. And the second path is to modify your C# or Java applications to use our .NET DLL to perform encryption at the application level.

Both approaches leverage our Microsoft .NET DLLs to perform encryption with integrated key management. Both are very simple to implement. And there are no additional license fees to deploy and use our Microsoft .NET DLLs to accomplish this.

Paul Taylor: So, walk me through the steps for encrypting data in my SQL Server Enterprise Edition database. How difficult is it?

Patrick Townsend: Encrypting data in Enterprise SQL Server is really very easy. The first step is to install our Alliance Key Manager for VMware solution. It launches like any other virtual machine using the normal VMware applications and you can have a key management solution up and running very quickly.

The second step is to install the Key Connection for SQL Server application on the virtual machine running SQL Server in Windows. This is a normal install process with an MSI file. You answer some questions, install a certificate and private key in the Windows Certificate Store, and run a handful of commands to start SQL Server TDE encryption or Cell Level Encryption. You also restart the log file to be sure that it is encrypted as well. That’s about it.

Of course, you will want to follow the instructions on how to set up a high availability key server, and point your Key Connection for SQL Server configuration to it as failover. That is a normal configuration process and also very easy to do. We find that VMware customers can deploy SQL Server encryption very quickly.

Paul and Patrick also cover which versions of SQL Server are supported, the availability of Alliance Key Manager in other platforms (hint: it’s quite versatile), and our 30-day evaluation program (you can do a full proof-of-concept in your own environment at no charge). Be sure to download the podcast to hear the rest of their conversation:

Podcast: VMware and SQL Server Encryption

Topics: Data Security, Encryption, Security Insider Podcast, Encryption Key Management, VMware, SQL Server

VMware and SQL Server Encryption – We Can Do That

Posted by Patrick Townsend on Dec 2, 2014 9:44:00 AM

VMware is hands-down the virtualization choice of large and small organizations. And it is easy to see why. Not only is it a highly reliable and scalable platform, but VMware provides a complete set of tools you need to deploy, manage, monitor, and protect virtual machines. And did I mention that it totally rocks the scalability challenge?

SQL Server Resource Kit on Encryption & Key ManagementLet’s look at how VMware customers who run Microsoft SQL Server applications can enable encryption and key management to protect sensitive data and meet compliance regulations.

First Step:

We have to solve the encryption key management challenge. As we like to say around here, the hardest part of security is encryption, and the hardest part of encryption is key management. We have to store the encryption keys separate from the protected data, and use industry standard practices to protect them. With our Alliance Key Manager for VMware solution we make this problem easy to solve. Our key manager comes in a ready-to-deploy OVA format and VMware customers can just launch the key manager with standard VMware tools. Of course, there are some security best practices on how to properly deploy a security application like a key manager in VMware (see the resources section below). With Alliance Key Manager’s Ready-To-Use options you can have your VMware key management problem solved in just SECONDS.

Of course, some of our VMware customers want to protect encryption keys in traditional Hardware Security Modules (HSMs). No problem, Alliance Key Manager can be deployed as a rack-mounted HSM or as a vCloud instance.

The Second Step:

Now we want to enable encryption in SQL Server and protect the encryption keys with Alliance Key Manager. Thanks to Microsoft’s Extensible Key Management (EKM) interface, this is incredibly easy. Alliance Key Manager comes with EKM Provider software that plugs right into SQL Server to enable encryption and protect your encryption keys. We call this our Key Connection for SQL Server application and it installs on your SQL Server VMware instance using a standard MSI install process. Key Connection for SQL Server runs in all SQL Server environments including VMware, hardware, vCloud, and cloud platforms so hybrid environments are fully supported. Install the credentials, select the SQL Server instances you want to protect, answer some questions, type a few commands and you have a fully protected SQL Server database using Transparent Data Encryption (TDE). Again, this takes just minutes to accomplish.

SQL Server also supports column level encryption, which Microsoft calls Cell Level Encryption. It can provide better performance for some SQL Server databases. Yes, that’s also supported through the same Key Connection for SQL Server software.

The beauty of the Microsoft EKM architecture is that you don’t need to modify your SQL Server applications to deploy encryption. Your DBA and security team can get your data protected very quickly without a development project. Anybody got budget for that these days?

Hint

Already encrypting SQL Server but aren’t protecting your encryption key? That’s easy – you can install Key Connection for SQL Server, issue a few commands, and the problem is solved!

The Third Step:

What about high availability, business recovery, clustered configurations, and system logs? We’ve got all of that covered, too. Using the same Key Connection for SQL Server EKM Provider (did I mention that it’s free?) you can configure one or more secondary key servers that function as high availability failover servers for business recovery? Key Connection for SQL Server will automatically failover to secondary key servers if the primary key server is unavailable.

Alliance Key Manager also fits nicely into your active monitoring strategy. You can easily enable forwarding of all key access, key management, encryption, and system activity logs to your log collection server or SIEM solution.

Celebrate Victory and Do It Again!

Alliance Key Manager protects Oracle, IBM, MySQL and other databases as well as web applications and unstructured data. You get to deploy one key management solution to protect everything. And do you know how much it will cost you to do your next project? Nothing, zilch, zed, nada! Alliance Key Manager does not force you to license and pay for client-side applications.

Hint

I’ll talk more in future posts about how to protect other databases and applications in VMware environments. Stay tuned if you run SharePoint, Microsoft CRM or ERP applications, Oracle, or open source databases like MySQL and SQLite.

How Much Better Can This Get?

You can evaluate Alliance Key Manager and Key Connection for SQL Server in your own VMware environment free of charge. Just visit our Alliance Key Manager for SQL Server page and request a free 30-day evaluation.

Encryption and key management? We can get this done right!

Resources:

PCI SSC Virtualization Guidelines

VMware Solution Guide for Payment Card Industry (PCI)

Securing Alliance Key Manager for VMwar

Alliance Key Manager for VMware Solution Brief

Resource Kit: Encrypting Data on SQL Server





Topics: Alliance Key Manager, Encryption, VMware, SQL Server

How To Meet PCI DSS Compliance With VMware

Posted by Michelle Larson on Sep 25, 2014 3:12:00 PM

Take the right steps to meet compliance in a virtualized environment

VMware encryption key managementWith executives looking to conserve resources by moving their organizations databases and IT environments to virtualized platforms and to the cloud, there are concerns around virtualized environments. Security best practices and compliance regulations call for sensitive data to be protected with encryption and that data-encrypting keys (DEK) be physically or logically separated from the sensitive data and protected with strong key-encrypting keys (KEK). Depending on what type of information is being stored and what industry guidance your project/company falls under, compliance regulations in addition to PCI DSS may apply.

The Payment Card Industry Data Security Standard (PCI DSS) is one of the most rigorous and specific set of standards established to date and is used by many organizations as a standard to secure their systems. PCI DSS applies to all organizations that store, process, or transmit cardholder data, regardless of volume. This includes merchants, service providers, payment gateways, data centers, and outsourced service providers.

Here is a high level look at all twelve items that must be met in order to be compliant, with three new requirements in PCI DSS 3.0 (**) that warrant mentioning as being most relevant to the use of VMware and cloud technologies in a PCI-regulated infrastructure:

Build and Maintain a Secure Network and Systems
Requirement 1: Install and maintain a firewall configuration to protect cardholder data


(3.0) **Req. 1.1.3: "[Maintain a] current diagram that shows all cardholder data flows across systems and networks."

Requirement 2: Do Not use vendor-supplied defaults for system passwords and other security parameters

(3.0)** Req. 2.4: "Maintain an inventory of system components that are in scope for PCI DSS."

Protect Cardholder Data

Requirement 3: Protect stored cardholder data*


* Requirement 3 specifically addresses the need for encryption and key management, stating:

“Protection methods such as encryption, truncation, masking, and hashing are critical components of cardholder data protection. If an intruder circumvents other security controls and gains access to encrypted data, without the proper cryptographic keys, the data is unreadable and unusable to that person. Other effective methods of protecting stored data should also be considered as potential risk mitigation opportunities. For example, methods for minimizing risk include not storing cardholder data unless absolutely necessary, truncating cardholder data if full PAN is not needed, and not sending unprotected PANs using end-user messaging technologies, such as e-mail and instant messaging.”

Requirement 4: Encrypt transmission of cardholder data across open, public networks

Maintain a Vulnerability Management Program

Requirement 5: Protect all systems against malware and regularly update anti-virus software or programs


Requirement 6: Develop and maintain secure systems and applications

Implement Strong Access Control Measures

Requirement 7: Restrict access to cardholder data by business need-to-know


Requirement 8: Identify and authenticate access to system components


Requirement 9: Restrict physical access to cardholder data

Regularly Monitor and Test Networks

Requirement 10: Track and monitor all access to network resources and cardholder data


Requirement 11: Regularly test security systems and processes

Maintain an Information Security Policy

Requirement 12: Maintain a policy that address information security for all personnel

(3.0) ** Req. 12.8.5: "Maintain information about which PCI DSS requirements are managed by each service provider and which are managed by the entity."

It can seem overwhelming at first, but the PCI Security Standards Council (PCI SSC) website contains this documentation along with a number of additional resources to assist organizations with their PCI DSS assessments and validations. Within the latest documentation by the PCI Security Standards Council (v3.0 released November 2013) specific testing procedures and guidance is given for Requirement 3 on pages 34-43.

Fortunately, there are also standards and published guidance on running payment applications in a virtualized environment:

Payment Card Industry Data Security Standard: Virtualization Guidelines and Cloud Computing Guidelines

NIST SP 800-144: Guidelines on Security and Privacy in Cloud Computing

Cloud Security Alliance: Security Guidance for Critical Areas of Focus in Cloud Computing

While virtual technology is not limited to VMware, it is one of the most commonly used and supported architectures by many cloud service providers. In addition to the PCI compliance and cloud guidelines above, VMware worked with CoalFire, a QSA auditing firm, to create guidance on how to specifically deploy payment applications in a VMware environment. You can access the CoalFire document from the VMware website here.

As platform virtualization becomes a more popular solution, executives need to remain vigilant with their data security and meeting compliance requirements. We can help make the transition to VMware easy with our Alliance Key Manager for VMware solution, which meets the PCI recommendations when deployed properly in a VMware environment. We are committed to helping businesses protect sensitive data with industry standard NIST compliant AES encryption and FIPS 140-2 compliant encryption key management solutions.


To learn more about enterprise key management for VMware and vCloud, download our podcast "Virtualized Encryption Key Management".

Podcast: Virtualized Encryption Key Management


Topics: Alliance Key Manager, PCI DSS, Encryption Key Management, VMware, Virtualized Encryption Key Management, Podcast, PCI, Cloud Security

Virtual Encryption Key Management - 5 Things to Look For

Posted by Liz Townsend on Jan 28, 2014 4:52:00 PM

Virtual encryption solutions are becoming more and more popular with organizations that are now running their applications and data centers on virtual machines and in the cloud. Although a traditional hardware security module (HSM) for key management may still be the most convenient encryption key management solution for some companies, a virtual encryption key management solution is ideal for companies who are moving to virtual machines and the cloud in order to reduce cost and complexity. Even in virtual and cloud environments, you must protect your sensitive data and manage your encryption keys in order to meet retail, healthcare, and financial regulations such as PCI-DSS, HIPAA/HITECH, and GLBA/FFIEC.

Listen to the Podcast on Key Management Options

Of course, choosing a virtual key management and cloud-based encryption vendor can be difficult. Heck--encryption key management has a reputation for being difficult in itself. That’s why when choosing a virtual encryption key management solution, it’s important to look for these four differentiating factors:

1. Free 30 day trial any time of the year. Any company who offers a free thirty day trial for only a limited period of time may not be giving you a chance. Sure, installing a virtual encryption key manager is faster and easier than deploying an HSM in your data center, but the backend decision making and evaluation in your company may take at least several weeks, if not months. Look for a virtual solution that you can deploy fast, but without the pressure of a limited trial, and when you’re ready.

2. Client side applications and SDKs. Every company’s IT infrastructure is different. One of the most frustrating aspects of adopting an encryption key management solution can be roadblocks associated with needing specialized solutions or software development kits (SDKs). Today many organizations utilize both a cloud solution as well as physical hardware. Your encryption key management vendor should provide you with resources to make securing these systems easy. Better yet, they should be free.

3. Help you move to any cloud service. The cloud is always growing. With so many different cloud vendors available to you, you’ll want the power to decide which cloud you choose to move to. Your virtual encryption key management vendor should be able to support your move to the cloud whether you decide to move to VMware’s vCloud, Windows Azure, or Amazon Web Services (AWS).

4. World-class, enterprise level encryption key management for businesses of any size. Cost should not be a barrier to security. Choosing a virtual encryption key management solution can be difficult, especially when you’re faced with a tight budget. You should always ask your potential encryption key management vendor about their pricing model--do they price per key manager instance as well as additional costs per connection? Can they scale their solution to meet your company’s needs?

5. Personal attention & world-class service. Bigger isn’t always better. In the complicated world of encryption and encryption key management, you want a vendor who can move fast, pay attention to detail, and be there for you in times of need.

Townsend Security offers NIST FIPS 140-2 compliant virtual encryption key management with the added bonus of specializing in scalable solutions to meet the needs of any size of company. Free 30 day trials have been and will always be available for all of our solutions during any time of the year.

Alliance Key Manager for VMware, vSphere, and vCloud, and Alliance Key Manager for Windows Azure provide full life-cycle management of encryption keys to help organizations meet PCI DSS, HIPAA, and FFIEC compliance in virtual and cloud instances.  With built-in key replication, key retrieval, and administrative controls, Alliance Key Manager virtual machine is a secure, reliable, and affordable key management solution for a wide variety of business applications and databases.  Additionally, Alliance Key Manager supports on-appliance encryption and decryption services so that your encryption key is always kept separate from the data it protects. We provide free client side applications and SDKs to make deployment faster and easier than ever.

Listen to the Podcast on Key Management Options

Topics: Encryption Key Management, VMware, Virtualized Encryption Key Management





Subscribe to Email Updates

Recent Posts

Posts by Topic

see all
